F-21-FUEL TANK
HONDADream Neo CB110CMH · 21 parts
Parts in This Assembly (21)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 16950-K63-D30 | COCK ASSY., FUEL | 1 | |
| 1 | 16950-K63-D31 | COCK ASSY., FUEL(UCAL) | 1 | |
| 1 | 16950-K63-D32 | COCK ASSY., FUEL(ADVIK) | 1 | |
| 2 | 17506-K23-900 | FILM A, TANK PROTECTOR | 1 | |
| 3 | 17507-K23-900 | FILM B, TANK PROTECTOR | 1 | |
| 4 | 17508-KVX-600 | RUBBER, RR. FUEL TANK MOUNTING | 1 | |
| 5 | 17509-K23-900 | COLLAR, FUEL TANK MOUNT | 1 | |
| 6 | 17520-K23-D60ZA | TANK ASSY., FUEL(WL) *TYPE4* | 1 | |
| 6 | 17520-K23-D60ZB | TANK ASSY., FUEL(WL) *TYPE3* | 1 | |
| 6 | 17520-K23-D60ZC | TANK ASSY., FUEL(WL) *TYPE2* | 1 | |
| 6 | 17520-K23-D60ZD | TANK ASSY., FUEL(WL) *TYPE1* | 1 | |
| 7 | 17611-KFN-850 | CUSHION, FR. FUEL TANK | 2 | |
| 8 | 17620-KTE-D03 | CAP COMP., FUEL FILLER (JAY USHIN) | 1 | |
| 9 | 17681-K63-D30 | TUBE, FUEL | 1 | |
| 10 | 37800-K63-D31 | FUEL UNIT | 1 | |
| 11 | 83551-376-000 | GROMMET, SIDE COVER | 2 | |
| 12 | 90652-KWP-F00 | CLIP, TUBE(B8) | 1 | |
| 13 | 91305-443-740 | O RING, 39.5 X 5 | 1 | |
| 14 | 94050-06000 | NUT, FLANGE, 6 MM | 4 | |
| 15 | 90602-K0L-D00 | CLIP, TUBE(C9) | 1 | |
| 16 | 95701-08035-08 | BOLT, FLANGE, 8X35 | 1 |
