F-23-10 - SIDE COWL
HONDA Dream Yuga CB110AMH · 25 parts
Parts in This Assembly (25)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 50400-K14-900ZD | GRIP, RR. *NH1* BLACK | 1 | |
| 1 | 50400-K14-900ZG | GRIP, RR. *R321* SPORTS RED | 1 | |
| 1 | 50400-K14-900ZJ | GRIP, RR. *NHB63P* PEARL AMAZING WHITE | 1 | |
| 2 | 77240-K14-960ZA | COWL SET, R. SIDE(WL)*TYPE5* | 1 | |
| 2 | 77240-K14-960ZB | COWL SET, R. SIDE(WL)*TYPE4* | 1 | |
| 2 | 77240-K14-960ZC | COWL SET, R. SIDE(WL)*TYPE3* | 1 | |
| 2 | 77240-K14-960ZD | COWL SET, R. SIDE(WL)*TYPE2* | 1 | |
| 2 | 77240-K14-960ZE | COWL SET, R. SIDE(WL)*TYPE1* | 1 | |
| 3 | 77250-K14-960ZA | COWL SET, L. SIDE(WL)*TYPE5* | 1 | |
| 3 | 77250-K14-960ZB | COWL SET, L. SIDE(WL)*TYPE4* | 1 | |
| 3 | 77250-K14-960ZC | COWL SET, L. SIDE(WL)*TYPE3* | 1 | |
| 3 | 77250-K14-960ZD | COWL SET, L. SIDE(WL)*TYPE2* | 1 | |
| 3 | 77250-K14-960ZE | COWL SET, L. SIDE(WL)*TYPE1* | 1 | |
| 4 | 77280-K14-960ZA | COWL SET, RR. CENTER(WL)*TYPE3* | 1 | |
| 4 | 77280-K14-960ZB | COWL SET, RR. CENTER(WL)*TYPE2* | 1 | |
| 4 | 77280-K14-960ZC | COWL SET, RR. CENTER(WL)*TYPE1* | 1 | |
| 4 | 77280-K14-960ZD | COWL SET, RR. CENTER(WL)*TYPE4* | 1 | |
| 5 | 83502-KCC-900 | GROMMET, SIDE COVER | 2 | |
| 6 | 83551-GE2-000 | GROMMET, AIR CLENER CASE | 2 | |
| 7 | 90101-GE0-000 | SCREW, HINGE PATCH | 4 | |
| 8 | 90666-SDA-A01 | CLIP , SNAP FIT (PO) | 4 | |
| 9 | 93903-35280 | SCREW, TAPPING, 5 X 12 | 2 | |
| 10 | 95701-08018-08 | BOLT, FLANGE, 8X18 | 4 | |
| 10 | 95702-08018-08 | BOLT, FLANGE, 8X18 | 4 | |
| 11 | 90111-162-000 | BOLT, FLANGE, 6MM | 2 | |
