F-50-STRIPE/MARK
HONDADream Yuga CB110AMF · 43 parts
Parts in This Assembly (43)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 86101-K14-900ZC | MARK, HONDA(70MM)*TYPE2* | 1 | |
| 1 | 86101-K14-960ZA | MARK, HONDA(70MM)*TYPE1* | 1 | |
| 2 | 86102-K14-900ZC | MARK, HONDA(60MM)*TYPE2* | 1 | |
| 2 | 86102-K14-Y00ZA | MARK, HONDA(60MM)*TYPE1* | 1 | |
| 11 | 86833-KWP-D00ZA | MARK, HET *TYPE1* | 1 | |
| 14 | 86111-K14-670 | EMBLEM, R. WING(100MM) | 1 | |
| 15 | 86121-K14-670 | EMBLEM, L. WING(100MM) | 1 | |
| 18 | 86171-K14-960ZA | STRIPE, R. FUEL TANK*TYPE4* | 1 | |
| 18 | 86171-K14-960ZB | STRIPE, R. FUEL TANK*TYPE3* | 1 | |
| 18 | 86171-K14-960ZC | STRIPE, R. FUEL TANK*TYPE2* | 1 | |
| 18 | 86171-K14-960ZD | STRIPE, R. FUEL TANK*TYPE1* | 1 | |
| 19 | 86172-K14-960ZA | STRIPE, L. FUEL TANK*TYPE4* | 1 | |
| 19 | 86172-K14-960ZB | STRIPE, L. FUEL TANK*TYPE3* | 1 | |
| 19 | 86172-K14-960ZC | STRIPE, L. FUEL TANK*TYPE2* | 1 | |
| 19 | 86172-K14-960ZD | STRIPE, L. FUEL TANK*TYPE1* | 1 | |
| 20 | 86611-K14-960ZA | STRIPE, R. FR. VISOR*TYPE4* | 1 | |
| 20 | 86611-K14-960ZB | STRIPE, R. FR. VISOR*TYPE3* | 1 | |
| 20 | 86611-K14-960ZC | STRIPE, R. FR. VISOR*TYPE2* | 1 | |
| 20 | 86611-K14-960ZD | STRIPE, R. FR. VISOR*TYPE1* | 1 | |
| 21 | 86612-K14-960ZA | STRIPE, L. FR. VISOR*TYPE4* | 1 | |
| 21 | 86612-K14-960ZB | STRIPE, L. FR. VISOR*TYPE3* | 1 | |
| 21 | 86612-K14-960ZC | STRIPE, L. FR. VISOR*TYPE2* | 1 | |
| 21 | 86612-K14-960ZD | STRIPE, L. FR. VISOR*TYPE1* | 1 | |
| 22 | 86771-K14-960ZA | STRIPE, R. SIDE COWL*TYPE5* | 1 | |
| 22 | 86771-K14-960ZB | STRIPE, R. SIDE COWL*TYPE4* | 1 | |
| 22 | 86771-K14-960ZC | STRIPE, R. SIDE COWL*TYPE3* | 1 | |
| 22 | 86771-K14-960ZD | STRIPE, R. SIDE COWL*TYPE2* | 1 | |
| 22 | 86771-K14-960ZE | STRIPE, R. SIDE COWL*TYPE1* | 1 | |
| 23 | 86772-K14-960ZA | STRIPE, L. SIDE COWL*TYPE5* | 1 | |
| 23 | 86772-K14-960ZB | STRIPE, L. SIDE COWL*TYPE4* | 1 | |
| 23 | 86772-K14-960ZC | STRIPE, L. SIDE COWL*TYPE3* | 1 | |
| 23 | 86772-K14-960ZD | STRIPE, L. SIDE COWL*TYPE2* | 1 | |
| 23 | 86772-K14-960ZE | STRIPE, L. SIDE COWL*TYPE1* | 1 | |
| 24 | 86831-K14-960ZA | STRIPE, R. SIDE COVER*TYPE5* | 1 | |
| 24 | 86831-K14-960ZB | STRIPE, R. SIDE COVER*TYPE4* | 1 | |
| 24 | 86831-K14-960ZC | STRIPE, R. SIDE COVER*TYPE3* | 1 | |
| 24 | 86831-K14-960ZD | STRIPE, R. SIDE COVER*TYPE2* | 1 | |
| 24 | 86831-K14-960ZE | STRIPE, R. SIDE COVER*TYPE1* | 1 | |
| 25 | 86832-K14-960ZD | STRIPE, L. SIDE COVER*TYPE2* | 1 | |
| 25 | 86832-K14-960ZC | STRIPE, L. SIDE COVER*TYPE3* | 1 | |
| 25 | 86832-K14-960ZB | STRIPE, L. SIDE COVER*TYPE4* | 1 | |
| 25 | 86832-K14-960ZA | STRIPE, L. SIDE COVER*TYPE5* | 1 | |
| 25 | 86832-K14-960ZE | STRIPE, L. SIDE COVER*TYPE1* | 1 |
