F-10-VX - FRONT WHEEL
Hero XOOM 110 BSVI OBD II(April,2023) · 24 parts
Parts in This Assembly (24)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 44601-AAW-D0099 | WHEEL COMP FRONT | 1 | |
| 2 | 42753-AAL-001 | RIM,VALVE | 1 | |
| 3 | 44301-AAW-000 | AXLE FR. WHEEL | 1 | |
| 4 | 44311-KPL-900 | COLLAR, FR. WHEEL SIDE | 1 | |
| 7 | 44620-AAW-000 | COLLAR FR WHEEL DISTANCE | 1 | |
| 8 | 44711-AAW-00099 | TYRE FR | 1 | |
| 13 | 45100-ACP-010 | PANEL COMP FR BRAKE | 1 | |
| 14 | 45125-AAH-F0099 | SHOE COMP BRAKE | 2 | |
| 15 | 45133-KCC-900 | SPRING, FR. BRAKE SHOE | 2 | |
| 16 | 45134-250-000 | DUST SEAL, BRAKE CAM | 1 | |
| 17 | 45141-AAW-000 | CAM FRONT BRAKE | 1 | |
| 18 | 45145-AAW-000 | INDICATOR FRONT BRAKE | 1 | |
| 19 | 45410-AAW-D00 | ARM FR BRAKE | 1 | |
| 20 | 45435-GB2-720 | SPRING, BRAKE ARM RETURN | 1 | |
| 21 | 45456-AAW-D00 | SPRING BRK CABLE END | 2 | |
| 22 | 45459-AAW-000 | NUT, BRAKE ADJUSTING | 2 | |
| 23 | 51502-AAW-000 | BRKT CABLE GUIDE BRAKE PANEL | 1 | |
| 24 | 95701-06032-00 | BOLT, FLANGE, 6 X 32 | 1 | |
| 25 | 43455-AAL-100 | JOINT BRAKE ARM | 2 | |
| 26 | 95701-06010-00 | BOLT, FLANGE, 6 X 10 | 1 | |
| 27 | 90754-KPL-900 | SEAL, DUST 20 X 32 X 5 | 1 | |
| 28 | 90912-KPL-900 | BEARING BALL RADIAL 6201(U) | 2 | |
| 31 | 90306-KST-942 | NUT, CASTLE, 12 MM | 1 | |
| 31 | 90306-KTE-911 | NUT, CASTLE, 12 MM | 1 | |
